Cell Antenna Unit
Issue 6 September 2001
3-31
!
WARNING:
CAUs cannot be installed in a return air plenum. The coaxial cable provided
(comcode 847565132) is rated for installation in air-handling spaces.
1. Unpack the CAU and obtain tie wrap.
2. Connect (twist) the fixed-length coaxial cable originating from the
appropriate WFB.
3. Loop the wrap around the tabs on the underside of the CAU (see the next
illustration).
If... Then...
the CAU is to be mounted using tie
wraps
go to Step 1
the CAU is to be installed using the
mounting plate
go to Step 4
the CAU is to be installed indoors
using the mounting brackets
go to the “Mounting the Indoor
CAU Brackets” section
the CAU is to be installed outdoors
using the mounting brackets
go to the “Mounting the Outdoor
CAU Brackets” section
To Next Page
