Avaya ESS User Manual

Enterprise Survivable Server - Troubleshooting
Issue 1.1 June 2005 169
Figure 51: Troubleshooting - list trace ras command example - Main server
3. Execute the trace command from the ESS server.
Use the IP Address obtained from the Configure ESS screen with the list trace ras command.
The same ESS / Main message exchange takes place. From this perspective the ESS server
sends a Registration Request (these appear as KARRQ messages at the Main server) and the
Main server responds with Registration Confirmation (RCF) messages.
Figure 52: Troubleshooting - list trace ras command example - ESS server
list trace ras ip-address 135.9.78.143 Page 1
LIST TRACE
time data
11:01:02 rcv RRQ endpt 135.9.78.143:1719 switch 135.9.72.168:1719 ext
11:01:02 snd RCF endpt 135.9.78.143:1719 switch 135.9.72.168:1719 ext
11:03:02 rcv KARRQ endpt 135.9.78.143:1719 switch 135.9.72.168:1719 ext
11:03:02 snd RCF endpt 135.9.78.143:1719 switch 135.9.72.168:1719 ext
11:04:02 rcv KARRQ endpt 135.9.78.143:1719 switch 135.9.72.168:1719 ext
11:04:02 snd RCF endpt 135.9.78.143:1719 switch 135.9.72.168:1719 ext
11:05:02 rcv KARRQ endpt 135.9.78.143:1719 switch 135.9.72.168:1719 ext
11:05:02 snd RCF endpt 135.9.78.143:1719 switch 135.9.72.168:1719 ext
11:06:02 rcv KARRQ endpt 135.9.78.143:1719 switch 135.9.72.168:1719 ext
11:06:02 snd RCF endpt 135.9.78.143:1719 switch 135.9.72.168:1719 ext
11:07:02 rcv KARRQ endpt 135.9.78.143:1719 switch 135.9.72.168:1719 ext
list trace ras ip-address 135.9.72.168 Page 1
LIST TRACE
time data
11:01:02 snd RRQ endpt 135.9.72.168:1719 switch 135.9.78.143:1719 ext
11:01:02 rcv RCF endpt 135.9.72.168:1719 switch 135.9.78.143:1719 ext
11:03:02 snd RRQ endpt 135.9.72.168:1719 switch 135.9.78.143:1719 ext
11:03:02 rcv RCF endpt 135.9.72.168:1719 switch 135.9.78.143:1719 ext
11:04:02 snd RRQ endpt 135.9.72.168:1719 switch 135.9.78.143:1719 ext
11:04:02 rcv RCF endpt 135.9.72.168:1719 switch 135.9.78.143:1719 ext
11:05:02 snd RRQ endpt 135.9.72.168:1719 switch 135.9.78.143:1719 ext
11:05:02 rcv RCF endpt 135.9.72.168:1719 switch 135.9.78.143:1719 ext
11:06:02 snd RRQ endpt 135.9.72.168:1719 switch 135.9.78.143:1719 ext
11:06:02 rcv RCF endpt 135.9.72.168:1719 switch 135.9.78.143:1719 ext
