Chapter 1 | About the Avaya Scopia
®
Application server
Avaya Scopia
®
Application server is a state of the art modern server optimized to run the Scopia
®
Solution software
products: Scopia
®
Management, Scopia
®
Desktop server, Content Center for Scopia
®
Desktop and Avaya Scopia
®
ECS Gatekeeper.
Avaya Scopia
®
Application server is a 1U device incorporating the latest Intel technology. It comes installed with
Windows 2012 R2 Server operating system, and its hardware supports the full capacity range of the applications it is
designed to run. It is also highly reliable, using a solid state drive (SSD), and has the ideal specifications to run
Scopia
®
Solution components.
This publication covers the latest Avaya Scopia
®
Application server (P/N 55876-00003).
Navigation
•
Technical Specifications and Environmental Requirements on page 4
•
Supported Capacity on page 5
Technical Specifications and Environmental Requirements
This section details the system specifications of the Avaya Scopia
®
Application server. Refer to this data
when preparing system setup and afterwards to verify the environment still complies with these
requirements.
The Avaya Scopia
®
Application server specifications are as follows:
•
CPU: Single Intel Xeon E3-1275V2 Quad Core, 3.5 GHz CPU
•
RAM: 8GB DDR3-1600MHz
•
SSD: 100GB
•
Ethernet: Dual 1GB NICs
1 x DB9 serial port connector
2 x USB 2.0 connectors
•
OS: Windows Server 2012 R2 Server
The hardware and environmental requirements are as follows:
•
System power requirements: 100-240 VAC, 50/60 Hz
•
Maximum power consumption: 200W (682 BTU/h)
•
Operating temperature: 10°C to 35°C (50°F to 95°F)
•
Relative humidity: 5% to 90% non-condensing
•
Storage temperature: -40°C to 70°C (-40°F to 158°F), ambient
•
Physical dimensions: Height: 43mm (1.7"), width: 437mm (17.2"); depth 664mm (26.1")
•
Net weight: Approx 11kg (24.25lbs)
Installation Guide for Avaya Scopia
®
Application Server Version 2 About the Avaya Scopia
®
Application server | 4
