7
Name Function
(14) Far/Near Select to control either near site or far site
camera. The cam ctrl icon will appear on the
screen to indicate which site’s camera you are
controlling. The cam ctrl icon will disappear
after press the Far/Near key 5 sec.
(15) Input Switch screen display between camera screen
and input source screen.
(16) Zoom +/- Increase/decrease the camera zoom or the
captured image magnifications.
(17) Vol +/- Increase/decrease the speaker volume.
(18) Mute Muto/Unmute the MIC. The mute icon will
appear when the MIC is muted. The mute icon
will become translucent after enabling 5 sec.
(19) Record Start/Stop video recording. The video
recording can only be saved to a USB flash
drive. You do not need to be on a video
conference to record.
(20) Presentation Share the content that comes from either the
VGA IN port source or the latest captured
image. The present icon will appear on the
screen when the presentation function is
enabled. The icon will disappear after 5 sec.
(21) Layout Change the screen layout.
(22) AVer Point Specified for some special functions. For
example, on the Phonebook configuration
screen of EVC application, press this button to
create a new Group. (Aver Point To be
developed)
(23) Preset a. Press and hold for 3 sec. to set the
position of the camera to a preset from
0~9.
b. Press to move the camera to a selected
preset point number.
(24) Snapshot Capture the image from the camera. To view
the captured image, press Present button. (To
be developed)
(25) Dual Switch to dual screen mode. This splits the
video conferencing screen and present screen
onto two separate monitors (two monitors must
be connected to use the feature, one through
HDMI and one through VGA).
