13
USB STORAGE (USB PORTS)
EVC main system supports two USB2.0 interface for saving data. One is located on the front panel of
main system; another is located on the back panel.
Before INSTALLATION
This chapter explains the best way to position EVC-Series in a conference room.
Using the Camera
EVC130P includes a detached camera that can pan (
∅
+-100 deg. range), tilt (
∅
+-25 deg. range) and
zoom (16x Optics) by using the , , , and zoom +/- buttons on remote controller.
Avoid physically turn camera while system is powered on to prevent permanent damaging the
motors and gears and void the warranty. Always use the remote control to pan and tilt the camera
head.
Infrared Sensor (IR)
Aim the remote controller at the camera infrared sensor to operate the unit.
