AVer VB130 User Manual

5
Remote Control
Name Function
1. SmartFrame
One-click automatic FOV adjustment to fit all participants in screen
for one time. Press and hold the button for 1~2 sec to switch from
manual to auto framing mode or Off.
An icon message (as figure shown) will display on the left upper
screen to indicate in SmartFrame status. The icon will appear 2~3
sec on the screen. Once the process is done, it will disappear. If
you don’t want to see the icon display, please go to PTZApp 2 or
Web setting, find “
On Screen Menu
” function and select “
Off
”.
[Notes]

SmartFrame deploys face and body detection technology.
People wearing masks or in side facial profiles can still be
detected. The maximum detection distance is 5 meters.

Camera will track people while moving. It will start to focus
and zoom in when people stop moving anymore for 1~5
seconds, depending on the framing speed you set up in
PTZApp 2 or Web page. The default framing speed is
“Middle” speed. “High” speed is more suitable for one
person tracking.

AVer VB130 Specifications

General

Megapixel	- MP
Sensor type	-
Digital zoom	4 x
White balance	Auto, Manual
Image sensor size	- \
Remote control interface	IR Wireless
Closest focusing distance	0.6 m
Field of view (FOV) angle	120 °
Number of microphone arrays	5
Product type	Group video conferencing system
Product color	Black, White
Wall mountable	Yes
Number of persons	- person(s)
Aspect ratio	4:3, 16:9
Maximum frame rate	60 fps
Video formats supported	M-JPEG, YUV, YUY2
Output level	92/96 dB
Frequency range	180 - 20000 Hz
RMS rated power	6 W
Microphone pick-up range	4 m
USB connector type	Mini-USB B, USB Type-A, USB Type-B
Windows operating systems supported	Windows 10, Windows 7
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	20 - 80 %
Cables included	AC, USB
Power cable length	3 m

Weight and Dimensions

Depth	75 mm
Width	350 mm
Height	65 mm
Weight	922 g
Package depth	146 mm
Package width	406 mm
Package height	189 mm
Package weight	2358 g
Remote control weight	50 g
Remote control dimensions (W x H x D)	42.3 x 19.29 x 149.72 mm
