AVer VB130 User Manual

14
Operating the Camera
Make a Video Call
1. Make sure all devices (VB130, laptop/PC, TV/monitor) are well connected and powered on.
2. Run your video application (Teams, Skype
TM
, Skype for Business, Google Hangouts
TM
, Zoom
TM
,
WebEx
TM
, Adobe Connect
TM
, WebRTC, etc.) on your laptop/PC.
3. Set the VB130 camera as the primary camera and speakerphone for your video application (refer
to your video application user guide). You can now make your call.
[Note] The VB130 is a plug-and-play conference camera. The system requires no special drivers, but
we do recommend installing the PTZApp 2 for a better user experience. For information on how to
install and use the PTZApp 2, refer to the PTZApp 2 section in this user manual.
Make a Connection through the Browser
VB130 has an Ethernet port for IP streaming and allows administrators to remotely control and set up
the camera via an internet access. Moreover, VB130 also supports RTSP and RTMP functions. For
more details, please refer to page 36~38 or contact our technical support. When USB streaming is on,
RTSP/RTMP functions will not work simultaneously.
1. Make sure the VB130 has an internet access connection.
2. Launch PTZApp 2* ( ) and connect VB130 to PC with USB cable. The camera default IP
address is 192.168.1.168.
[Note] The browser supports:
 Chrome: version 76.x or above  Firefox: version 69 or above  IE: Doesn’t support

AVer VB130 Specifications

General

Megapixel	- MP
Sensor type	-
Digital zoom	4 x
White balance	Auto, Manual
Image sensor size	- \
Remote control interface	IR Wireless
Closest focusing distance	0.6 m
Field of view (FOV) angle	120 °
Number of microphone arrays	5
Product type	Group video conferencing system
Product color	Black, White
Wall mountable	Yes
Number of persons	- person(s)
Aspect ratio	4:3, 16:9
Maximum frame rate	60 fps
Video formats supported	M-JPEG, YUV, YUY2
Output level	92/96 dB
Frequency range	180 - 20000 Hz
RMS rated power	6 W
Microphone pick-up range	4 m
USB connector type	Mini-USB B, USB Type-A, USB Type-B
Windows operating systems supported	Windows 10, Windows 7
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	20 - 80 %
Cables included	AC, USB
Power cable length	3 m

Weight and Dimensions

Depth	75 mm
Width	350 mm
Height	65 mm
Weight	922 g
Package depth	146 mm
Package width	406 mm
Package height	189 mm
Package weight	2358 g
Remote control weight	50 g
Remote control dimensions (W x H x D)	42.3 x 19.29 x 149.72 mm
