AVer VB130 User Manual

7
again.

Audio fence:
Microphone only picks up the sound within
viewing angle. Adjust the
camera viewing area via
PTZApp 2 or IP Web
page to silence the
sound beyond the
meeting area.
[Note]
All the AI tracking
functions will be disabled while audio fence is on.
3. Bluetooth

Hold it for 1~2 sec to enable Bluetooth pairing with mobile
phone.

Short press it again to disconnect Bluetooth.
[Note] Wireless dongle is an optional item. Please contact your
local dealer for purchasing.
4. Mute/Unmute Mute/Unmute the speakerphone.
5. Camera Directional Control
Use the directional button on the remote to control the direction of
the camera. Press the directional button to move the camera or
press and hold for continuous pan or tilt.
6. Enter
Press to show the current AI function on screen such as Auto
Framing.
7. Call/Answer
Answer a call or start a call.
8. End Call
End the call.
9. OSD Menu
Not supported.
10. Load Preset Hotkey
Press to move to preset position as user has set in sequence.
11. Zoom In/Zoom Out
Increase/Decrease the camera zoom.
12. Volume Up/Down
Adjust volume up or down.
13. Compound Key

When pressing this button, the following photo will show up.
Then press the corresponding number key for setting up
specific function.

FOV:
Press
then to change field of view.

WDR:
Press
then to enable/disable the WDR
function.

Presentation mode:
Press
then to setup
presentation area while under presentation mode. (Press
button to enter presentation mode. After adjusting the desired

AVer VB130 Specifications

General

Megapixel	- MP
Sensor type	-
Digital zoom	4 x
White balance	Auto, Manual
Image sensor size	- \
Remote control interface	IR Wireless
Closest focusing distance	0.6 m
Field of view (FOV) angle	120 °
Number of microphone arrays	5
Product type	Group video conferencing system
Product color	Black, White
Wall mountable	Yes
Number of persons	- person(s)
Aspect ratio	4:3, 16:9
Maximum frame rate	60 fps
Video formats supported	M-JPEG, YUV, YUY2
Output level	92/96 dB
Frequency range	180 - 20000 Hz
RMS rated power	6 W
Microphone pick-up range	4 m
USB connector type	Mini-USB B, USB Type-A, USB Type-B
Windows operating systems supported	Windows 10, Windows 7
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	20 - 80 %
Cables included	AC, USB
Power cable length	3 m

Weight and Dimensions

Depth	75 mm
Width	350 mm
Height	65 mm
Weight	922 g
Package depth	146 mm
Package width	406 mm
Package height	189 mm
Package weight	2358 g
Remote control weight	50 g
Remote control dimensions (W x H x D)	42.3 x 19.29 x 149.72 mm
