AVer VB130 User Manual

23
 Audio Tracking: Camera pans/tilts (ePTZ) until speaker is centered before zooming in. The
camera moving path will be shown in the screen.
 Audio Frame: Once detecting human sound, camera focuses on speaker, shows the speaker in
view, and zooms in without showing moving path in the screen.
 Audio Preset Tracking: Set up preset points in advance before enabling this mode. Once
detecting human sound, camera will track the specific area but not zoom in the person. (Only for
Preset points 1~9. Preset 0 is for home position).
 Presentation Mode: This is a combination of preset tracking and audio frame. First, set up a
presentation area for tracking. For example, select the whole white board as presentation area.
Press Edit button.
Use◄,▼▲, ►, and zoom in/out button to adjust presentation area. Press
SAVE to confirm the setting. When a person talks in this area, camera will immediately shoot this
area. When someone speaks outside of this area, camera will move to frame him. When there is no
human sound and no people’s face or body being detected for more than 3 mins, the camera will
shoot back to this area.

You can also use remote control by pressing
and then to setup presentation area
while under presentation mode. Press
button to enter presentation mode. After adjusting the
desired image proportion and position, press
then to confirm the presentation area to
start this function. Please notice that this area is beyond 0~9 preset points on remote control.

AVer VB130 Specifications

General

Megapixel	- MP
Sensor type	-
Digital zoom	4 x
White balance	Auto, Manual
Image sensor size	- \
Remote control interface	IR Wireless
Closest focusing distance	0.6 m
Field of view (FOV) angle	120 °
Number of microphone arrays	5
Product type	Group video conferencing system
Product color	Black, White
Wall mountable	Yes
Number of persons	- person(s)
Aspect ratio	4:3, 16:9
Maximum frame rate	60 fps
Video formats supported	M-JPEG, YUV, YUY2
Output level	92/96 dB
Frequency range	180 - 20000 Hz
RMS rated power	6 W
Microphone pick-up range	4 m
USB connector type	Mini-USB B, USB Type-A, USB Type-B
Windows operating systems supported	Windows 10, Windows 7
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	20 - 80 %
Cables included	AC, USB
Power cable length	3 m

Weight and Dimensions

Depth	75 mm
Width	350 mm
Height	65 mm
Weight	922 g
Package depth	146 mm
Package width	406 mm
Package height	189 mm
Package weight	2358 g
Remote control weight	50 g
Remote control dimensions (W x H x D)	42.3 x 19.29 x 149.72 mm
