Avery Dennison Monarch 9855 - Setting the Cut Position; Setting the Dispense Position

Setting the Cut Position
This function adjusts where the tag is cut. The printer adjusts the cut
position according to the black marks on the supply. You may need to adjust
for aperture supplies. Increase to move the cut up; decrease to move the
cut down.
To change the setting, from the Main Menu, select Setup, Supply, then
Positioning. Then, follow these steps.
1. Press » or ¼ until you see
POSITIONING
» Cut Pos ¼
2. Press Enter/Pause. The current setting is displayed, for example:
Enter knife adj
[-300/300]: +0
3. Press » or ¼ to change the cut position. Pressing » decreases the
value (moves the cut down); ¼ increases it (moves the cut up).
Note: We do not recommend setting a positive cut position while using
extended backfeed. You may cut off the leading edge of the next
tag.
4. Press Enter/Pause when the number you need appears. Press
Escape/Clear until you see the Main Menu.
Setting the Dispense Position
This function adjusts the stopping point of the label.
To change the setting, from the Main Menu, select Setup, Supply, then
Positioning. Follow these steps.
1. Press » or ¼ until you see
POSITIONING
»Dispense Pos ¼
4-12 Operator's Handbook
