Using Batch Separators
A batch separator is an extra tag printed in between batches with a pinstripe
pattern. If you select "Long" for the separator, a double-length (two tags)
separator prints. For non-indexed supply, the batch separator is always six
inches long. If you have the Monarch® 928™ stacker installed, the batch
separator is 3.66 inches long. The name of the batch is shown on the batch
separator.
Batch Separator
Note: Changing this setting only affects new formats sent to the printer.
To change the setting, from the Main Menu, select Setup, then Supply.
Then, follow
these steps.
1. Press » or ¼ until you see
SUPPLY
» Separators ¼
2. Press Enter/Pause to set the batch separators option. The current
setting is displayed, for example:
SEPARATORS
No ¼
3. Press » or ¼ to see the other options. After you display the option you
want, press Enter/Pause. Press Escape/Clear until you see the Main
Menu.
4-14 Operator's Handbook
