56 XR Series Installation and Technical Instructions
Specifications
Power: • Input - 90 to 240 VAC, 50/60 Hz
• 115/230 VAC autosensing power supply
• Consumption - XR2000: 25 watt (60 watt max)
XR4500, 4500TL, 6500: 60 watt
Display: • 6 digit, 7 segment, high intensity (Precision Optical Performance) red
LED lamp
• 2” characters (XR 2000), 60 foot viewing range
4.5” characters (XR 4500 and XR 4500TL), 275 foot viewing range
6.5” characters (XR 6500), 325 foot viewing range
• 1 or 2 decimals (XR 4500, XR 4500TL and XR 6500) up to 5 decimals
(XR 2000)
• 4 annunciators (GR, NT, lb, KG)
• Capacity - (-99999 to 999999)
Input Data Interface: • RS-232, RS-485, 20 mA Current Loop (active or passive), wireless RF
Data Format: • Baud Rates - 300 to 19,200, Auto-learning or selectable
• 7 or 8 data bits, even, odd, or no parity; 1 or 2 stop bits, Auto-learning
or selectable
Output Interface • Echo out port - RS-232
Update: • Continuous or demand, selectable
Operating Environment: • -40°F to 120°F (-40°C to 50°C) 0% to 100% humidity, noncondensing
Enclosure: • Weatherproof, powder-coated, mild steel
• Nonglare, contrast lens
Dimensions: • XR 2000 - 12 7/8” x 6” x 2 1/4” (327mm x 152mm x 57mm)
• XR 4500 - 24” x 5” x 10” (610mm x 127mm x 254mm)
• XR 4500TL / XR 6500 - 32” x 5” x 12” (813mm x 127mm x 305mm)
Shipping Weight: • XR 2000 - 6 lb (3kg)
• XR 4500 - 18 lb (9kg)
• XR 4500TL / XR 6500 - 32 lb (15kg)
Warranty • 2 year limited
Specifications
