Avery Weigh-Tronix XR Series - Base Station Wireless Transceiver

XR Series Installation and Technical Instructions 29
Base Station Wireless
Transceiver
The XStream base station is shown in Figure 4.2. The label on the unit
identifies the various inputs and outputs of the base station.
Figure 4.2 Base station (connects to the indicator)
Figure 4.3 shows the left end of the base station.
Figure 4.3 Base station, view 1
Figure 4.4 shows the opposite end of the base station.
Figure 4.4 Base station, view 2
