Chapter 2: Overview 7
Stage 48 Back Panel
Power Switch
The Power switch applies power to the Stage 48.
AC Power Connector
The AC power connector accepts a standard IEC AC power ca-
ble. The Stage 48 is auto-power selecting (100VAC to
240VAC). It automatically works with a standard modular
power cable when connected to an AC receptacle in any coun-
try.
Figure 2. Stage 48 back panel
Power switch
AC power connector
