EN 46
2.6 - MANUAL MOVEMENT
To be able to manoeuvre the gate manually, you
must disengage the geared motor.
Warning:
When the geared motor is disengaged, the gate
may be set in motion by the wind or an external
push. It is therefore important to be careful or
block the gate to avoid any risk of injury.
2.7 - MOTOR DISENGAGEMENT
• Turn off the motor before disengaging it.
• Insert the key into the lock.
• Turn the key clockwise to release the override
lever.
• Lower the override lever completely by first
pressing on its right side.
2.8 - MOTOR ENGAGEMENT
• Return the override lever to the initial position.
• Turn the key anticlockwise.
• After the power is restored, on the first command,
the gate will perform a full opening movement at
slow speed in order to align itself with the opening
stop.
E - USE
CONNECTED MOTOR DRIVE KIT
