4 - ANOMALY GUIDE
TYPE OF FAULT PROBABLE CAUSE WHAT YOU SHOULD DO
When activating the opening
command, the gate does not
move and the motor does not
start
No 230-volt power supply Switch the power back on
Emergency stop pressed and/or
the optional safety edge has failed
Connect the STOP terminals to the
earth.
Check the safety edge
Fuse(s) blown Replace the fuse(s) with (a) fuse(s)
of identical value
When activating the opening
command, the motor starts but
the gate does not move
There is not enough closing and
opening force
Adjust the force setting according
to the instructions (page 31)
Check that the rollers are
lubricated or are not impeded by
an obstacle on the ground
Lubricate the rollers and let the gate
move freely
Lock with the key lever
Check that the engine is engaged
The gate closes instead of
opening
The motor is connected the
wrong way round
Check the wiring according to the
instructions provided (see “motor
polarity”)
The gate opens but does not
close
Photocells not aligned Check the alignment and wiring
Obstacle in front of the photocells
or other
Verify the clearance
When activating the closing
command, the gate partially
closes
The motor is connected the
wrong way round
Check the wiring according to the
instructions provided (see “motor
polarity”)
In operation, there may be events that are
malfunctions of the motor drive, or consequences
of the user’s action. Each event has a different code.
This code is displayed by a combination of red LEDs
that are on or off on the
MENU 0 display.
When you press “SET” or “PROG”, this code is
deleted. However, the last 4 codes generated are
memorised, and can be viewed in a history.
To access them, press SET twice, then use the “+”
and “–” buttons to scroll through the memorised
codes.
To diagnose any problems, here is the list of codes
and their meaning:
/ / / / /
/ / / / /
/ / /
: LED off
/ / / / /
/ / / / /
/ / /
: LED on
There are two types of code: Error (E) or Information
(I). N.B. an error requires action from the installer to
correct the motor drive problem.
