EN49
L1 L2 L3 L4 L5 Meaning Type
The emergency stop input has been activated
I
A card power supply fault has been detected. It may be a short-circuit
on the +12V output.
Check the connections.
E
An obstacle has been detected in the gate when opening.
I
The photocell beam has been cut
I
Photocell self-test failure. The PHO input has remained earthed.
Check the connections.
E
Photocell self-test failure. The PHO is never earthed (this is normal if
no photocells are connected). Check the connections.
E
Photocell self-test failure. The TX photocell power supply has caused
a short-circuit.
Check the connections.
E
The main power supply has been cut during a movement phase OR
the battery is too weak for proper operation.
E
The battery voltage is really too low for the card to work.
E
Self-learning is not valid because it has never been done. Run self-
learning.
E
Automatic closure has been cancelled. Generated if the gate re-
opens 3 times (10 in collective mode) after a photocell beam has been
obstructed during automatic closure OR if the photocell beam was
obstructed for more than 3 minutes. Check photocell operations.
E
The full opening control input ( ) is permanently earthed.
Check the connections.
E
The partial opening control input ( ) is permanently earthed.
Check the connections.
E
An obstacle has been detected in the gate when closing
I
The maximum operating time has been reached (the motor is idle and
is not reaching the stop?). Check the installation and that the motor
is engaged.
E
Battery voltage too low when attempting to close the gate
E
Three obstacles detected in a row during opening
I
Three obstacles detected in a row during closing
I
No battery detected
Check the connections.
E
