Aviom A360-MEE - Dante Patching

61
A360 PersonAl Mixer User GUide
A-16D P RO
AN-16/i v.2
AN-16/i v.2
AN-16/i v.2
AN-16/i v.2
A-16II
D800
e
to/from Personal Mixers
Load
Power
Sync
12345678
D800
I II I II I II I II I III II I III II
Channels 1-16Channels 1-16
Channels 17-32Channels 17-32
Channels 33-48Channels 33-48
Channels 49-64Channels 49-64
Select A360 mix channels from all
64 network channels (
CUSTOM mode)
Select A360 mix channels from all
64 network channels (CUSTOM mode)
A320s use channels
1-32 of the network
A320s use channels
1-32 of the network
A-16IIs and A-16Rs
utilize Channels
1-16 only
A-16IIs and A-16Rs
utilize Channels
1-16 only
to additional
Personal Mixers
to additional
Personal Mixers
A 64-input system using two A-Net Distributors is shown.
Legacy products such as the A-16II or A-16R Personal Mixers may be used in a Pro16e-based system, but
note that they can only access the first 16 network slots.
