User’s Manual
8-12
Assembling Procedure
1. Insert the left end of the ADF roller to the left hole of the
slot. Make sure the left end of the ADF roller is inserted
and revealed as shown in below.
Figure 8-12
2. Insert two wire legs to the holes of the slot as shown in
below.
Figure 8-13
