UNPACKING
This chapter provides details about the contents of a complete product package, along with instructions on how
to safely unpack the product and, if needed, initiate a product return.
Package Contents
The following tables contains an overview of the package contents of the Product.
No. Quantity Description Avonic SKU
1 1 pc PTZ Camera AV-CM70/71/73-IP-B/W
2 1 pc Remote Control AV-CM40-RC
3 1 pc USB cable type A to type A AV-USB20-AA
4 1 pc Power Adapter 12V/A (GME Technology (Shenzhen) Co.,
ltd , model number: GME24A - 120200FDS2)
AV-CM40-PSU
5 1 pc RS-232 9-pin D-Sub female to DIN -8 male AV-CM-RS-232
6 1 pc 5-way Phoenix Balanced audio con. (CTBP92HE/5) AV-PHNX-5
7 1 pc 2-way Phoenix RS-485 connector AV-PHNX-2
Each item is visualized below and referenced by the associated number in the table above:
Figure 4: Package Contents
Power Adapter Usage
Note
: * Use only the Power Adapter of GME Technology (Shenzhen) Co., ltd with model number: GME24A -
120200FDS2 in combination with the CM70 series camera. Using another Power Adapter may lead to injury
and/or damage to the product. See the picture of the Power Adapter label at the left:
Figure 5: Power Adapter label Figure 6: Power plugs
* The power plug cable included with the power adapter may vary based on the image provided in the
package contents. This depends on the electrical system that is used in the country you live in. This is the case for
UK and Australian customers for example. See the picture above at the right.
13
