Avonic CM70-IP Series User Manual

Inquiry Commands
all parameter values are in hex
•
x = camera address
•
y = socket number
•
z = camera address + 8
Inquiry Commands
Command Function Command Packet Comments
CAM_ZoomPosInq 8x 09 04 47 FF 90 50 0p 0q 0r 0s FF pqrs: Zoom Position
90 50 02 FF Auto Focus
90 50 03 FF Manual Focus
CAM_FocusAFModeInq 8x 09 04 38 FF
90 50 04 FF OnePush Focus
CAM_FocusPosInq 8x 09 04 48 FF 90 50 0p 0q 0r 0s FF pqrs: Focus Position
90 50 00 FF Auto
90 50 01 FF Indoor mode
90 50 02 FF Outdoor mode
90 50 03 FF OnePush mode
CAM_WBModeInq 8x 09 04 35 FF
90 50 05 FF Manual
CAM_RGainInq 8x 09 04 43 FF 90 50 00 00 0p 0q FF pq: R Gain
CAM_BGainInq 8x 09 04 44 FF 90 50 00 00 0p 0q FF pq: B Gain
CAM_GainInq
(CM70 series ONLY)
8x 09 04 0C FF 90 50 00 FF Manual Exposure Direct Gain
90 50 00 FF Full Auto
90 50 03 FF Manual
90 50 0A FF Shutter priority
90 50 0B FF Iris priority
CAM_AEModeInq 8x 09 04 39 FF
90 50 0D FF Bright
CAM_ShutterPosInq 8x 09 04 4A FF 90 50 00 00 0p 0q FF pq: Shutter Position
CAM_IrisPosInq 8x 09 04 4B FF 90 50 00 00 0p 0q FF pq: Iris Position
CAM_BrightPosInq 8x 09 04 4D FF 90 50 00 00 0p 0q FF pq: Bright Position
90 50 02 FF OnCAM_ExpComp-ModeInq 8x 09 04 3E FF
90 50 03 FF Off
CAM_ExpCompPosInq 8x 09 04 4E FF 90 50 00 00 0p 0q FF pq: ExpComp Position
90 50 02 FF OnCAM_Backlight-ModeInq 8x 09 04 33 FF
90 50 03 FF Off
CAM_Noise2DLevel 8x 09 04 53 FF 90 50 0p FF Noise Reduction (2D) p: 0 to 7, 8
= AUTO
CAM_Noise3DLevel 8x 09 04 54 FF 90 50 0p FF Noise Reduction (3D) p: 0 to 8
CAM_FlickerModeInq 8x 09 04 55 FF 90 50 0p FF p: Flicker Settings(0:
OFF, 1: 50Hz, 2: 60Hz)
90 50 02 FF Auto SharpnessCAM_Aperture-ModeInq
(Sharpness)
8x 09 04 05 FF
90 50 03 FF Manual Sharpness
CAM_ApertureInq(Sharpness) 8x 09 04 42 FF 90 50 00 00 0p 0q FF pq: Aperture Gain
90 50 00 FF ColorCAM_PictureEffectModeInq 8x 09 04 63 FF
90 50 04 FF B&W
70
