Avonic CM70-IP Series User Manual

Inquiry Commands
Command Function Command Packet Comments
CAM_MemoryInq 8x 09 04 3F FF 90 50 0p FF p: Memory (Preset) number last
operated.
90 50 02 FF OnSYS_MenuModeInq 8x 09 06 06 FF
90 50 03 FF Off
90 50 02 FF OnCAM_LR_ReverseInq 8x 09 04 61 FF
90 50 03 FF Off
90 50 02 FF OnCAM_PictureFlipInq 8x 09 04 66 FF
90 50 03 FF Off
CAM_ColorGainInq 8x 09 04 49 FF 90 50 00 00 00 0p FF p: Color Gain setting
0h (60%) to Eh (200%)
CAM_BTuningInq 81 09 0A 01 13 FF 90 50 pp FF pp = setting
-10 ~ +10 (00~14 HEX)
CAM_RTuningInq 81 09 0A 01 12 FF 90 50 pp FF pp = setting
-10 ~ +10 (00~14 HEX)
90 50 00 FF 1920x1080p60
90 50 01 FF 1920x1080p50
90 50 02 FF 1920x1080i60
90 50 03 FF 1920x1080i50
90 50 04 FF 1280x720p60
90 50 05 FF 1280x720p50
90 50 06 FF 1920x1080p30
90 50 07 FF 1920x1080p25
90 50 08 FF 1280x720p30
90 50 09 FF 1280x720p25
90 50 0A FF 1920x1080p59.94
90 50 0B FF 1920x1080i59.94
90 50 0C FF 1280x720p59.94
90 50 0D FF 1920x1080p29.97
VideoSystemInq
(CM40 series: It is possible to set the
video format, but since the video
format is dictated by the computer
the camera is connected with,
the picture will not change to that
format.)
8x 09 06 23 FF
90 50 0E FF 1280x720p29.97
Pan-tiltMaxSpeedInq 8x 09 06 11 FF 90 50 ww zz FF ww: Pan Max Speed
zz: Tilt Max Speed
Pan-tiltPosInq 8x 09 06 12 FF 90 50 0w 0w 0w 0w
0z 0z 0z 0z FF
wwww: Pan Position
zzzz: Tilt Position
8x 09 04 2C FF 90 50 0q FF p: Gain LimitCAM_GainLimitInq
8x 09 04 2C FF 90 50 07 FF Auto exposure
CAM_DHotPixelInq 8x 09 04 56 FF 90 50 0q FF p: Dynamic Hot Pixel Setting (0:
0ff, level 1 to 6)
90 50 01 FF High
90 50 02 FF Normal
CAM_AFSensitivityInq 8x 09 04 58 FF
90 50 03 FF Low
CAM_BrightnessInq 8x 09 04 A1 FF 90 50 00 00 0p 0q FF pq: Brightness Position
CAM_ContrastInq 8x 09 04 A2 FF 90 50 00 00 0p 0q FF pq: Contrast Position
71
