h. Set & Clear Preset
A preset is a specific position of a camera that you save in the camera. A preset is assigned to a number from 0-9.
1. To set a preset, first point the camera in a specific directing and a specific zoom position.
2. Assign the position to a number with the button Set Preset.
3. You can call the preset by pressing one of the numbers 0-9 on the remote control.
Set Preset: [SET PRESET]→[<number>]
Call Preset: [<number>]
Clear Preset: [CLEAR PRESET]→[<number>]
If the position preset '0' has been stored, this position will be called after initialization.
Use ONLY presets between 0-9 when using the Remote Control. For presets 10 or higher you need a serial
or IP connection!
i. PTZ Keys (up/down/left/right)
Use these keys to move the camera in the desired direction.
j. Home
Use this key to set the direction of the camera to the center position.
k. BLC ON/OFF
Use this key to enable / disable the Back Light Control feature.
l. Menu
1. Use the Menu button to open the On Screen Display (OSD) menu. This menu is visible on the
HDMI/SDI output.
2. If the menu is not in English, press [*]→[#]→[4] to change the Menu language into English.
m. Function Keys (F1/F2/F3/F4)
Used to configure the IR channel of the camera. See 'c. Camera Select' above for instructions.
n. Blank Buttons
These buttons have NO function with this camera.
43
