Avonic CM70-IP User Manual

Camera Control Commands
Command Function Command Packet Comments
CAM_NR(3D)Level - 8x 01 04 54 0p FF p: NR Setting (0: Off,
level 1 to 8)
CAM_Flicker - 8x 01 04 23 0p FF p: Flicker Settings
(0: Off, 1: 50Hz, 2: 60Hz)
CAM_DHotPixel - 8x 01 04 56 0p FF p: Dynamic Hot Pixel Setting (0: 0ff,
level 1
to 5)
Reset 8x 01 04 02 00 FF
Up 8x 01 04 02 02 FF
Down 8x 01 04 02 03 FF
Aperture ControlCAM_Aperture (sharpness)
Direct 8x 01 04 42 00 00 0p 0q FF pq: Aperture Gain
Off 8x 01 04 63 00 FFCAM_PictureEffect
B&W 8x 01 04 63 04 FF
Picture Effect Setting
Reset 8x 01 04 3F 00 pp FF
Set 8x 01 04 3F 01 pp FF
CAM_Memory(preset)
Recall 8x 01 04 3F 02 pp FF
pp: Memory Number (=0 to 127)
On 8x 01 04 61 02 FFCAM_LR_Reverse
Off 8x 01 04 61 03 FF
Image Flip Horizontal On/Off
On 8x 01 04 66 02 FFCAM_PictureFlip
Off 8x 01 04 66 03 FF
Image Flip Vertical On/Off
Freeze ON 8x 04 04 62 02 FF Freeze ON immediately
Freeze OFF 8x 04 04 62 03 FF Freeze OFF immediately
Preset Freeze ON 8x 04 04 62 22 FF Freeze ON when running preset
Freeze
(CM70 series ONLY)
Preset Freeze OFF 8x 04 04 62 23 FF Freeze OFF when running preset
Off 8x 01 06 06 03 FFSYS_Menu
On 8x 01 06 06 02 FF
Turns the OSD menu On/Off
CAM_ColorGain Direct 8x 01 04 49 00 00 00 0P FF p: Color Gain setting
0h (60%) to Eh (200%)
