Avonic CM70-IP User Manual

Camera Control Commands
Command Function Command Packet Comments
CAM_ColorHue Direct 8x 01 04 4F 00 00 00 0p FF p: Color Hue setting0h (− 14
degrees) to
Eh (+14 degrees
High SpeedPan/Tilt ON 8x 0A 01 31 03 FF High Speed PTONPan-tilt_MaxSpeed
High SpeedPan/Tilt OFF 8x 0A 01 31 02 FF High Speed PTOFF
ARM/MCU_Version Inquiry ARM/MCU
Version
8x 09 0A 01 03 FF Returned version in HEX, for
example: 02 05 00 (version 2.5.0)
CAM/UVC_Version Inquiry Cam/UVC
version
8x 09 00 02 FF Returned version in HEX, for
example: 02 05 09 (version 2.5.9)
Red 8x 01 7E 01 0A 00 02 03 FF Tally Light RedON
Green 8x 01 7E 01 0A 00 03 02 FF Tally Light GreenON
CAM_TallyLight(Cm7x only
with license active)
Off 8x 01 7E 01 0A 00 03 03 FF Tally Light OFF
Preset_H_Speed Horizontal (Pan) speed
between presets
81 01 03 01 qq FF qq= speed setting1 ~ 25 (1 = 00
HEX,
25 = 18 HEX)
Preset_V_Speed Vertical (Tilt) speed between
presets
81 01 03 02 qq FF qq = speed setting1 ~ 21 (1 = 00
HEX,
21 = 14 HEX)
Preset_Z_Speed Zoom speed between
presets
81 01 03 03 qq FF qq = speed setting1 ~ 8 (1 = 00
HEX,
8 = 07 HEX)
Blue_Tuning
(autowhitebalance active)
more or less blue while
maintaining auto white
balance active
81 0A 01 13 pp FF pp = setting
-10 ~ +10(00~14 HEX)
Red_Tuning
(autowhitebalance active)
more orless red while
maintaining auto white
balance active
81 0A 01 12 pp FF pp = setting
-10 ~ +10(00~14 HEX)
Camera Control Commands
Command Function Command Packet Comments
pp: Video Format
00: 1080p60
01:1080p50
02: 1080i60
03: 1080i50
04: 720p60
05: 720p50
06: 1080p30
07: 1080p25
08: 720p30
09: 720p25
0A: 1080p59.94
0B: 1080i59.94
0C: 720p59.94
0D: 1080p29.97
VideoSystem_Set
(CM40 series: It is possible to set the video format, but since
the video format is dictated by the computer the camera is
connected with, the picture will NOT change to that format.)
8x 01 06 35 00 pp FF
0E: 720p29.97
64
