Avonic CM70-IP User Manual

Color and Image
Camera Settings
Color
Function Code Command Setting
WB Mode {"SetEnv":{"VideoParam":
[{"stColor":{"stWbMode":
{"emWbMode":0}},"nChannel":0}]}}
emWbMode 0:
1:
7:
2:
8:
4:
9:
Auto
3000K
3500K
4000K
4500K
5000K
5500K
10:
6:
11:
5:
3:
6000K
6500K
7000K
Manual
OnePush
RG Tuning {"SetEnv":{"VideoParam":[{"stColor":
{"rgaintuning":0},"nChannel":0}]}}
rgaintuning [0, 20]
BG Tuning {"SetEnv":{"VideoParam":[{"stColor":
{"bgaintuning":20},"nChannel":0}]}}
bgaintuning [0, 20]
Saturation {"SetEnv":{"VideoParam":[{"stColor":
{"saturation":0},"nChannel":0}]}}
saturation [0, 14]
Hue {"SetEnv":{"VideoParam":[{"stColor":
{"hue":14},"nChannel":0}]}}
hue [0, 14]
AWB
Sensitivity
{"SetEnv":{"VideoParam":[{"stColor":
{"awbsens":0},"nChannel":0}]}}
awbsens 0:
1:
2:
Low
Middle
High
Bright {"SetEnv":{"VideoParam":[{"stImg":
{"luminance":0},"nChannel":0}]}}
luminance [0, 4]
Contrast {"SetEnv":{"VideoParam":[{"stImg":
{"contrast":0},"nChannel":0}]}}
contrast [0, 14]
Sharpness {"SetEnv":{"VideoParam":[{"stImg":
{"sharpness":1},"nChannel":0}]}}
sharpness [0, 15]
Gamma {"SetEnv":{"VideoParam":[{"stImg":
{"gamma":0},"nChannel":0}]}}
gamma [0, 4]
0: Default
1: 0.45
2: 0.50
3: 0.55
4: 0.63
DCI {"SetEnv":{"VideoParam":[{"stImg":
{"dci":0},"nChannel":0}]}}
dci [0, 8]
0:
OFF
B&W Mode {"SetEnv":{"VideoParam":[{"stImg":
{"nBWMode":0},"nChannel":0}]}}
nBWMode 0:
4:
Color
B & W
Flip-H {"SetEnv":{"VideoParam":[{"stImg":
{"nFlipH":3},"nChannel":0}]}}
nFlipH 2:
3:
ON
OFF
Camera Settings
Function Code Command Setting
Flip-V {"SetEnv":{"VideoParam":[{"stImg":
{"nFlipV":2},"nChannel":0}]}}
nFlipV 2:
3:
ON
OFF
AutoFlip {"SetEnv":{"VideoParam":[{"stImg":
{"nAutoFlipV":2},"nChannel":0}]}}
nAutoFlipV ON
OFF
79
