REMOTE OPERATION
28
6.2. IE Web Browser
Note: The supported PC operation systems are Windows Vista / XP / 2000.
Step 4: Key in the IP address used by your DVR in the URL address box, such as 60.121.46.236, and press
Enter. You will be prompted to enter the user name and password to access the DVR.
If the port number your DVR used is NOT 80, you need to key in the port number additionally. The format
is ipaddress:portnum. For example, for IP address 60.121.46.236 and port No. 888, please key
in ”http://60.121.46.236:888” into the URL address box, and press “Enter”.
Step 5: Enter the user name and password, the same as the ones used for video viewer login, and press “OK”.
You will see a screen when the login information is correct.
Note: The buttons and functions described below may differ from the actual ones and are for selected
model(s) only.
Function Description
Home
Click
to go to the main page of the DVR
Config.
Click
to go to the detailed DVR setting.
PTZ
Click
to enter the PTZ mode.
Single Channel
Selection
Click the channel No. to see the live view of the selected channel.
You can also press
or to go to the previous / next channel of the selected channel.
Display Mode
Click the display mode you want to see. There are 3 modes for your choice:
Click
/ / to show 4-cut / 9-cut / 16-cut display.
Snapshot
Click
to take a snapshot for the current view, and open another browser window to display the captured
image.
Selection
Click
or to go to the previous / next channel, or change setting.
