APPENDIX 7 SPECIFICATIONS
38
APPENDIX 7 SPECIFICATIONS
‧ Model 1 ~ 4
MODEL Model 1 Model 2 Model 3 Model 4
Video System NTSC / PAL (auto detection)
Video Input (composite video
signal 1 Vp-p 75Ω BNC)
16 channels 8 channels
Video Output (composite video
signal 1 Vp-p 75Ω BNC)
Main monitor output
Audio Input / Output
4 audio inputs, 1 audio
output (Mono)
1 audio input, 1 audio
output (Mono)
4 audio inputs, 1 audio
output (Mono)
1 audio input, 1 audio
output (Mono)
Maximum Recording Rate (Frame)
120 IPS @ 704×480 <NTSC> /
100 IPS @ 704×576 <PAL>
60 IPS @ 704×480 <NTSC> /
50 IPS @ 704×576 <PAL>
Maximum Recording Rate (Field)
240 IPS @ 704×240
<NTSC> /
200 IPS @ 704×288
<PAL>
N/A
120 IPS @ 704×240
<NTSC> /
100 IPS @ 704×288
<PAL>
N/A
Maximum Recording Rate (CIF)
480 IPS @ 352×240 <NTSC> /
400 IPS @ 352×288 <PAL>
240 IPS @ 352×240 <NTSC> /
200 IPS @ 352×288 <PAL>
Adjustable Recording Speed
(Frame)
120, 60, 30, 15 IPS <NTSC> /
100, 50, 25, 12 IPS <PAL>
60, 30, 15, 7 IPS <NTSC> /
50, 25, 12, 6 IPS <PAL>
Adjustable Recording Speed
(Field)
240, 120, 60, 30 IPS
<NTSC> /
200, 100, 50, 25 IPS
<PAL>
N/A
120, 60, 30, 15 IPS
<NTSC> /
100, 50, 25, 12 IPS
<PAL>
N/A
Adjustable Recording Speed (CIF)
480, 240, 120, 60 IPS <NTSC> /
400, 200, 100, 50 IPS <PAL>
240, 120, 60, 30 IPS <NTSC> /
200, 100, 50, 25 IPS <PAL>
Multilingual OSD YES
Image Quality Setting Best, High, Normal and Basic
Hard Disk Storage Accommodates 2 SATA HDDs ( 1 HDD capacity up to 1TB)
Quick Search Time / Motion / Alarm
search mode
Time / Motion search
mode
Time / Motion / Alarm
search mode
Time / Motion search
mode
SATA Interface Built-in
VGA Interface
Built-in (output resolution
up to 1600 x 1200)
N/A
Built-in (output resolution
up to 1600 x 1200)
N/A
Recording Mode
Manual / Timer / Motion /
Alarm / Remote
Manual / Timer / Motion /
Remote
Manual / Timer / Motion /
Alarm / Remote
Manual / Timer / Motion /
Remote
Refresh Rate 480 IPS for NTSC / 400 IPS for PAL 240 IPS for NTSC / 200 IPS for PAL
Multiplex Operation
Live display / record (16 channels) / playback
(simultaneously up to 4 channels) / backup / network
operations
Live display / record (8 channels) / playback
(simultaneously up to 4 channels) / backup / networ
k
operations
Remote Independent Operation Fully remote independent operation
R.E.T.R.
(Remote Event Trigger Recording)
YES N/A YES N/A
Motion Detection Area
16 × 12 grids per camera
for all channels
3 pre-defined detection
areas selectable
16 × 12 grids per camera
for all channels
3 pre-defined detection
areas selectable
Motion Detection Sensitivity One parameter with three sensitivity levels (High / Normal / Low)
Pre-alarm Recording YES (8 MB)
