MAIN MENU
15
b) In “CHANNEL”, select “ALL” to apply the changes here to all channels.
QUICK START
MANUAL EVENT TIMER
CHANNEL IMAGE SIZE I.P.S. QUALITY
ALL CIF 100 SUPER BEST
EXIT
Note: The I.P.S. section is taking the PAL system as an example.
Or, select “BY CHANNEL” to set the image size, image per second & image quality individually for each
channel.
QUICK START
MANUAL EVENT TIMER
CHANNEL IMAGE SIZE I.P.S. QUALITY
CH1 CIF 25 SUPER BEST
CH2 CIF 25 SUPER BEST
CH3 CIF 6 HIGH
CH4 FIELD 25 SUPER BEST
AVAILABLE IPS: CIF 69 / FIELD 34 / FRAME 17
APPLY EXIT
5.1.2 TIME SETUP
QUICK START
GENERAL DATE 2009 / NOV / 17
TIME SETUP TIME 15 : 35 : 53
EXIT
1) DATE
Set the current date. The default display format is YEAR – MONTH – DATE (Y-M-D).
Note: To change the date display format, please refer to “5.2.1 DATE INFO”.
2) TIME
Set the current time in HOUR : MIN : SEC.
To Next Page
