CH11 W X
DETECTION BRIGHTNESS 128
ALERT CONTRAST 128
NETWORK SATURATION 128
DISPLAY HUE 128
RECORD COV. OFF
DEVICES REC ON
DCCS CHANNEL TITLE EDIT
IVS
NOTIFY
EXIT
1) BRIGHTNESS / CONTRAST / SATURATION / HUE
Click the current value to manually adjust the brightness/contrast/saturation/hue of each channel here.
2) COV.
Select if you want to mask the selected channel under recording (ON / OFF). When this function is activated,
the wording “COV.” will be shown on the channel screen.
Note: To hide the wording “COV.” When this function is on, go to “DISPLAY”, and set “DISPLAY COVERT”
to “OFF”. For details, please refer to “5.5.6 DISPLAY” at page 25.
3) REC
Select if you want to enable recording for the selected channel (ON / OFF).
Note: When this function is disabled, no manual, event or timer recording will be activated even if any
of these three record functions is set to “ON”.
4) CHANNEL TITLE
Click “EDIT” to input the channel title (up to six characters). The default title is the channel number.
5.5.2 DETECTION
ADVANCED CONFIG
C A N E R A CH1 CH2 CH3
CH11 W X
DETECTION LS 07
ALERT SS 03
NETWORK TS 02
DISPLAY MOTION OFF
RECORD ALARM OFF
DEVICES AREA EDIT
DCCS
IVS
NOTIFY
EXIT
1) LS (Level of Sensitivity)
“LS” is to set the sensitivity of comparing two different images. The smaller the value is, the higher sensitivity
for motion detection. The highest sensitivity setting is 00, and the lowest sensitivity setting is 15. The default
value is 07.
2) SS (Spatial Sensitivity)
“SS” is to set the sensitivity for detecting the size of one object (the number of the grids) on the screen. The
smaller the value is, the higher sensitivity for motion detection.
The highest sensitivity setting is 00, and the lowest sensitivity setting is 15. The default setting is 03.
