23
8) ALARM DURATION (SEC)
Select the duration time for alarm buzzer in second (5 / 10 / 20 / 40).
9) HDD NEARLY FULL (GB)
If HDD BUZZER is enabled, select the duration time for buzzer notifications when the hard disk available
capacity is 5/10/15/20 GB left.
5.5.4 NETWORK
NETWORK
The description below is only for STATIC network type. For PPPOE and DHCP settings, you need to set from
“Video Viewer”.
For details, please download the extended user manual for “Video Viewer” from
http://www.surveillance-download.com/user/CMS.pdf.
S
S
T
T
A
A
T
T
I
I
C
C
ADVANCED CONFIG
CANERA NETWORK
DETECTION NETWORK TYPE STATIC
ALERT IP 192.168.001.010
NETWORK GATEWAY 192.168.001.254
DISPLAY NETMASK 255.255.255.000
RECORD PRIMARY DNS 168.095.001.001
DEVICES SECONDARY DNS 139.175.055.244
DCCS PORT 0080
IVS APPLY
NOTIFY
EXIT
1) NETWORK TYPE
Select the network type as STATIC and set all the information needed in the DVR.
2) NETWORK INFORMATION (IP / GATEWAY / NETMASK)
Key in all the network information obtained from your ISP (Internet Service Provider).
3) DNS (PRIMARY DNS / SECONDARY DNS)
Key in the IP address of the domain name server obtained from your ISP (Internet Service
Provider).
4) PORT
The valid number ranges from 1 to 9999. The default value is 80. Typically, the TCP port used by
HTTP is 80. However in some cases, it is better to change this port number for added flexibility or
security.
