APPENDIX 1 SPECIFICATIONS
51
AVC799B AVC797B
Alarm I/O 16 inputs, 1 output 8 inputs, 1 output
Key Lock (Password Protection) YES
Local User Level Administrator & Operator
Video Loss Detection YES
Camera Title Supports up to 12 letters
Video Adjustable Hue / Saturation / Contrast / Brightness
Date Display Format YY/MM/DD, DD/MM/YY & MM/DD/YY
Daylight Saving YES
Power Source (±10%) DC 19V
Power Consumption (±10%) < 64 W
Operating Temperature 10 ~ 40 (50 ~104 )℃℃℉℉
Dimensions (mm)** 432(W) × 90(H) × 326(D)
System Recovery System auto recovery after power failure
Optional Peripherals Keyboard controller
* The specifications are subject to change without notice.
** Dimensional Tolerance: ±5mm
