OXYGEN 1000 & OXYGEN 2000 · User Manual · ENG
SURFACE |TALKBOX CONNECTIONS
F. STUDIO SPEAKERS / CUT-ATT-MODE
SETUP / AUDIO / OUTPUTS / MONITOR / SPEAKER / SPK-STUDIO / CUT-ATT-MODE
CUT MODE: it’s allowed the microphone to CUT OFF the audio of control room loudspeakers once the
microphone goes to ON.
The opening of a microphone channel (if configured appropriately) can generate the closing command
of the loudspeakers.
That is possible to choose one or more microphone to cut the loudspeaker output of the Studio by
following this path:
SETUP / AUDIO / INPUTS / MIC / SPK-CUT (OFF, ST, CR, CR+ST)
When you select ST, if the configured Studio Mics are on the CUT indicator will blink as described by
the following picture only on the OXYGEN REMOTER.
When you open the associated source with a CUT function you will see it will MUTE Studio
Loudspeakers output to prevent LOOP audio and the SPEAKER icon on the OXYGEN REMOTER will
start blinking.
ATT. (attenuation) MODE: It helps reduce acoustic flux from flowing into the speakers.
It possible to decrease the speakers output -40, -30, -20 or -10 dB.
EX.: If we want to reduce the sound coming out of the speakers by 40 dB less than the current
value, then we have to choose -40. The same thing if we want to reduce the current volume when
opening any of the microphones with a value of 10 decibels, then we have to choose -10 and
confirm the selection by pressing the button around until the selection color changes to yellow.
The CUT mode is triggered by the change from OFF to ON of a microphone source to which it has
been set closing of the loudspeaker.
As shown in the MENU this function (CUT) is associated only with the loudspeakers, to avoid
LARSEN effects “feedback loop” from occurring between the nearby loudspeakers and On-Air
microphones.
