OXYGEN 1000 & OXYGEN 2000 · User Manual · ENG
TELEPHONE LINES USAGE AND CONNECTIONS |EXTERNAL TELCO DEVICE
5.2.2 ADDITIONAL TELCO LINES
It is possible to use 4 more additional TELCO lines (TELCO 2 / TELCO 3 / TELCO 4 / TELCO 5) by setting
the console with the correct parameters.
The following F1 MODE parameter could be set individually for each additional TELCO, in this
example we are showing you the correct setting for TELCO 2:
SETUP / AUDIO / INPUTS / TEL/BT / TELCO 2 / GENERAL / F1 MODE = TELEPHONE
to assign the HOOK / DROP function to the related F1 button.
This parameter only affects the channel on which you have assigned the TELCO 2 source (not
TELEPHONE, BLUETOOTH, TELCO 1, TELCO 3, TELCO 4).
The same F1 setting could be found into each TELCO input and will not affect the other TELCOs.
5.2.3 ADDITIONAL TELCO INPUT LINES
ANALOG-IN-1 could be configured as 2 different mono TELCO inputs:
TELCO 2: ANALOG-IN-1-L
TELCO 3: ANALOG-IN-1-R
to use the 2 above signals as 2 separate telco input lines please set the related parameter as follow:
MAIN/AUDIO/SETTINGS/INPUT MODE/LINE 1 MODE = 2 TELCO
after this setting the choosable source will be no more only ANALOG-IN-1 but the 2 input signals will
be labeled in the source list as TELCO 2 and TELCO 3.
DANTE-IN-1 could be configured as 2 different TELCO mono inputs:
TELCO 4: DANTE-IN-1-L
TELCO 5: DANTE-IN-1-R
NB: If your console does not have the DANTE option you can not have TELCO 4 and TELCO 5. The only available additional
TELCO will be TELCO 2 and TELCO 3.
to use the 2 above signals as 2 separate telco input lines please set the related parameter as follow:
MAIN/AUDIO/SETTINGS/INPUT MODE/DANTE 1 MODE = 2 TELCO
