TELEPHONE LINES USAGE AND CONNECTIONS|EXTERNAL TELCO DEVICE
OXYGEN 1000 & OXYGEN 2000 · User Manual · ENG
5.2.4 ADDITIONAL TELCO OUTPUT LINES (clienfield / N-1 logic)
OUT-2 (ANALOG-OUT-2) source could be configured as 2 different TELCO mono outputs:
TELCO 2: ANALOG-OUT-2-L
TELCO 3: ANALOG-OUT-2-R
to use the 2 above signals as 2 separate telco output lines please set the related parameter as follow:
MAIN/AUDIO/OUTPUTS/ANALOG/OUT-2/ source = N-1 T2/T3
TELCO 2 caller can also listen TELCO 3 caller
TELCO 3 caller can also listen TELCO 2 caller
or
MAIN/AUDIO/OUTPUTS/ANALOG/OUT-3/ source = N-1 T2+T3
TELCO 2 caller can not listen for TELCO 3 caller
TELCO 3 caller can not listen for TELCO 2 caller
DANTE-OUT-1 could be configured as 2 different TELCO mono outputs:
- TELCO 4: DANTE-OUT-1-L
- TELCO 5: DANTE-OUT-1-R
to use the 2 above signals as 2 separate telco output lines please set the related parameter as follow:
MAIN/AUDIO/OUTPUTS/DIGITAL/DANTE-1/ source = N-1 T4/T5
- TELCO 4 caller can also listen TELCO 5 caller
- TELCO 5 caller can also listen TELCO 4 caller
or
MAIN/AUDIO/OUTPUTS/DIGITAL/DANTE-1/ source = N-1 T4+T5
- TELCO 4 caller can not listen for TELCO 5 caller
- TELCO 5 caller can not listen for TELCO 4 caller.
