OXYGEN 1000 & OXYGEN 2000 · User Manual · ENG
93
TECH SPECS |NAVIGATION MODE - ACTIVATION
Nominal Output Level
0dBu
Max Output Level (clipping point)
+19dBu
D/A conversion
24 bit / 48 Khz
Signal to Noise Ratio (referred to peak level)
>90dB
Stereo Separation (referred to peak level)
>80dB
THD+N
<0,05%
Analog Balanced Talkbox Outputs
Connector
RJ45 balanced – EMI Suppressed
Output Impedance
100ohm, nominal 600ohm
Nominal Output Level
0dBu
Max Output Level (clipping point)
+14dBu
D/A conversion
24 bit / 48 Khz
Signal to Noise Ratio (referred to peak level)
>100dB
Stereo Separation (referred to peak level)
>90dB
THD+N
<0,05%
Analog Balanced Telco Output
Connector
XLR Balanced – EMI Suppressed
Output Impedance
23ohm, nominal 600ohm
Nominal Output Level
0dBu
Max Output Level (clipping point)
+18,5dBu
D/A conversion
24 bit / 48 Khz
Signal to Noise Ratio (referred to peak level)
>100dB
THD+N
<0,002%
Digital Input
Connector
Balanced on 1 XLR – EMI Suppressed
Input Impedance
110Ω
