Axis 207W User Manual

11
AXIS 207W/AXIS 207MW - Accessing the Camera
The Live View Page
The buttons described below may or may not be visible; this would depend on how you
have customized the Live View page.
AMC audio controls
These control the client computer’s speaker output. The
controls are only available in
MPEG-4 video format and when audio is enabled, see Audio, on page
19.
The Video Format drop-down list allows the video format on the Live View
page to be temporarily changed.
The Trigger buttons can trigger
an event directly from the Live View page.
These are configured under S
etup > Live View Config > Layout.
The Snapshot button shows a snapshot of the video image currently displayed.
Right-click on the video image to save it in JPEG format. This button is
primarily intended
for use when the AMC viewer toolbar is not available.
The AMC viewer
toolbar (AXIS Media Control) is available in Microsoft Internet
Explorer only. It can display the following buttons:
The Play
/Stop button starts and stops the live video stream.
The Snapshot button saves a snapshot of the video image currently displayed.
The Snapshot function and the target directory for saving snapshots can be
con
figured from the AMC Control Applet, which can be opened from the
Windows Control Panel or by right-clicking the image in Internet Explorer.
Click the View Full
Screen button to make the video image fill the entire
screen area. Press Esc (Escape) on
the computer keyboard to exit full screen.
Click the Record button to start a
video recording. This must be enabled in
Setup > Live View Config > Layout
Click the Mute/Sound button
to switch the sound off and on.
Use the slider to control the volume.
The volume can be set between 0
and 100.
The two different Output
buttons control the output
directly from the Live View
page. These are configured from
Setup > Live View Config >
Layout.
Pulse - click this button to activate the
output for a defined period of time, e.g.
to switch on a light for 20 seconds.
Active/Inactive - click these buttons to
manually start and stop a connected
device, e.g. switch a light on/off.
