AXIS 207W/AXIS 207MW - Technical Specifications
Technical Specifications
Item Specification
Model • AXIS 207W: VGA, wired and wireless interface
• AXIS 207MW: Megapixel, wired and wireless interface
Image sensor • AXIS 207W: ¼” Micron Progressive Scan RGB VGA CMOS
• AXIS 207MW: 1/3” Progressive S
can RGB; 1.3 Megapixel CMOS
Lens • AXIS 207W: 4.0 mm, F2.0, fixed iris, focus range: 0.5 m to infinity
AXIS 207MW: 3.6 mm, F1.8, fixed iris, focus range: 0.5 m to infinity
Angle of view • AXIS 207W: Horizontal: 55°
• AXIS 207MW: Horizontal: 74°
Illumination • AXIS 207W: 1-10000 lux, F2.0
• AXIS 207MW: 2-10000 lux, F1.8
Video compression • Motion JPEG
• MPEG-4 Part 2 (ISO/IEC 14496-2) with motion estimation,
• Profiles: Simple Profile level 0-3 and Advan
ced Simple Profile level 0-5
Resolutions • AXIS 207W: 7 resolutions up to 640x480
• AXIS 207MW: 15 resolutions up to1280x1024
Frame rates • AXIS 207W: Up to 30 fps in all resolutions
• AXIS 207MW: up to 14 fps in resolutions up to 1280x720, up to 12 fps in 1280x1024
Video streaming • Simultaneous Motion JPEG and MPEG-4
• Controllable frame rate and bandwidth
• VBR/CBR MPEG-4
• 3GPP and ISMA compatible
Image settings • Compression levels: 100
• Rotation: 0º, 180º
• Mirroring
• Configurable color level, brightness, contrast, white balance
• Overlay capabilities: time, date, text
Shutter time • AXIS 207W:1/2-1/10000 sec
• AXIS 207MW: 1/10-1/10000 sec
Audio • Built-in microphone for one-way audio
• Audio compression:
AAC LC 8-32 kbit/s
G.711 PCM 8 kHz
G.726 ADPCM 8 kHz
