AXIS 221/223M Installation Guide Page 3
ENGLISH
AXIS 221/223M Network Camera
Installation Guide
This installation guide provides instructions for installing the AXIS 221/223M Network
Camera on your network. For all other aspects of using the product, please see the
AXIS 221/223M User’s Manual, available on the CD included in this package, or from
www.axis.com
Installation steps
Follow these steps to install the AXIS 221/223M on your local network (LAN):
1. Check the package contents against the list below.
2. Connect the camera. See page 4
3. Set an IP address. See page 6
4. Set the password. See page 12
Package contents
Important!
Item Notes
Network Camera AXIS 221/223M
CS lens adaptor ring (AXIS 223M only)
Power adapter Country-specific
Camera stand Includes 1 adjustable screw mount, 1 base plate
Terminal block connectors 1 x 10-pin connector block for connecting external devices to the I/O terminal connector
1 x 3-pin connector block for connecting power to the 3-pin power connector
AXIS Network Video CD including Installation tool and other software, product documentation
Printed Materials • AXIS 221/223M Installation Guide (this document)
• Axis Warranty Document
To use the AXIS 221/223M outdoors it must be installed in a protective housing. For more information on
protective housings and other accessories, please visit www.axis.com

Axis 221 Specifications

General

Maximum resolution	640 x 480 pixels
Supported video modes	-
Video formats supported	MPEG4
Camera shutter speed	1/25000 - 2 s
Minimum illumination	0.08 lx
Sensor type	CCD
Progressive scan	Yes
Optical sensor size	1/3 \
Optical zoom	- x
Focus adjustment	1.0
Focal length range	3 - 8 mm
Built-in HDD	No
Flash memory	8 MB
Internal memory	32 MB
Type	IP security camera
Certification	EN 55022 B, EN 55024, EN 61000-3-2, EN 61000-3-3, \\r EN 61000-6-1, EN 61000-6-2, FCC 5 B B, \\r VCCI B, C-tick AS/NZS CISPR22, ICES-003 B, \\r EN 60950-1
Placement supported	Indoor
Connectivity technology	Wired
Form factor	Bullet
Product color	Gray
Housing material	Aluminum
Ethernet LAN (RJ-45) ports	1
Cabling technology	10/100Base-T(X)
Supported network protocols	IPv4/v6, HTTP, HTTPS, QoS Layer 3 DiffServ, FTP, SMTP, Bonjour, UPnP, SNMPv1/v2c/v3 (MIB-II), DNS, DynDNS, NTP, RTSP, RTP, TCP, UDP, IGMP, RTCP, ICMP, DHCP, ARP, SOCKS
AC input voltage	24 V
Power source type	PoE
Power consumption (typical)	7.5 W
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	20 - 80 %
Compliance industry standards	IEEE 802.3a

Weight and Dimensions

Weight	550 g
