Axis 221 Installation Guide

Page 6 AXIS 221/223M Installation Guide
Setting the IP address
The AXIS 221/223M is designed for use on an Ethernet network and must be assigned an IP
address to make it accessible.
Windows
Notes:
• The AXIS 221/223M has the default IP address 192.168.0.90
• If setting the IP address fails, check that there is no firewall blocking the operation.
See page 9 for other available methods for setting or discovering the IP address of the AXIS
221/223M e.g. in other operating systems.
AXIS IP Utility and AXIS Camera Management are the recommended methods for setting an IP address in Windows.
DHCP Server
in network
Operating system Recommended
method for:
AXIS IP Utility
See page 7
Optional Windows single camera /
small installations
AXIS Camera Management
See page 8
Optional Windows 2000/ XP Pro
Windows 2003 Server
multiple cameras /
large installations
Requirements
methods
Installation

Axis 221 Specifications

General

Maximum resolution	640 x 480 pixels
Supported video modes	-
Video formats supported	MPEG4
Camera shutter speed	1/25000 - 2 s
Minimum illumination	0.08 lx
Sensor type	CCD
Progressive scan	Yes
Optical sensor size	1/3 \
Optical zoom	- x
Focus adjustment	1.0
Focal length range	3 - 8 mm
Built-in HDD	No
Flash memory	8 MB
Internal memory	32 MB
Type	IP security camera
Certification	EN 55022 B, EN 55024, EN 61000-3-2, EN 61000-3-3, \\r EN 61000-6-1, EN 61000-6-2, FCC 5 B B, \\r VCCI B, C-tick AS/NZS CISPR22, ICES-003 B, \\r EN 60950-1
Placement supported	Indoor
Connectivity technology	Wired
Form factor	Bullet
Product color	Gray
Housing material	Aluminum
Ethernet LAN (RJ-45) ports	1
Cabling technology	10/100Base-T(X)
Supported network protocols	IPv4/v6, HTTP, HTTPS, QoS Layer 3 DiffServ, FTP, SMTP, Bonjour, UPnP, SNMPv1/v2c/v3 (MIB-II), DNS, DynDNS, NTP, RTSP, RTP, TCP, UDP, IGMP, RTCP, ICMP, DHCP, ARP, SOCKS
AC input voltage	24 V
Power source type	PoE
Power consumption (typical)	7.5 W
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	20 - 80 %
Compliance industry standards	IEEE 802.3a

Weight and Dimensions

Weight	550 g
