23
AXIS 221 - Live View Config
Output Buttons
These buttons can then be used to manually activate the output from the Live View page,
e.g. to switch a light on and off. There are 2 options for how the output is activated:
• The Pulse button activates the output for a defined period
• Active/Inactive displays 2 buttons, one for each action (on/off)
Default Video Format in Internet Explorer for Windows.
Select default video format from the drop-down list. Check the box to enable video format
selection on the Live View Page. When using MPEG-4 as video format, the default viewer
is AXIS Media Control with Internet Explorer.
Note: It is also possible to view Motion JPEG when MPEG-4 is chosen as default and vice versa.
AXIS Media Control Settings (see AXIS Media Control, on page 19)
Check the Show viewer toolbar box to display the AXIS Media Control (AMC) viewer
toolbar under the video image in your browser. The toolbar is only available when using
AMC.
Default Viewer for Motion JPEG.
Select the appropriate radio button to define the method for viewing moving video images,
depending on your browser and settings.
Please see the online help for more information.
HTML Examples
You can add live video from the camera to your own web site. The camera can transmit a
Motion JPEG stream to up to 20 simultaneous connections, although an administrator can
restrict this to fewer. If MPEG-4 is set as video format, multicasting is used and the video
stream will be available for an unlimited number of viewers connected to the parts of the
network where multicast is enabled. Please note that a separate MPEG-4 license is required
for each viewer.
Enter the Video Format, Image Type, Image size and other settings to suit your Web page
and click Update. The camera then generates the required source code for your
configuration. Copy this code and paste it into your own Web page code.
