AXIS 221 - Live View Config
External Video
The camera can also display video images from other Axis network cameras and video
servers. These are known as External Video sources. Each external video source is
available from the drop-down list on the Live View page.
Click the Add button to open the External Video Source Setup dialog, which is used to
make all the necessary settings. Enter the IP address or host name of the external video
source you wish to add. The user can then choose to receive either MPEG-2, MPEG-4 or
Motion JPEG video stream.
Sequence Mode
The Live View page can be configured to rotate through the internal and selected external
video sources, in order, or randomly.
Select the desired video sources and enter the time in seconds to display each source (up to
59 minutes). Click Save.
The Sequence buttons will appear on the Live View page to enable the viewer to start and
stop the sequence mode.
Please see the online help for more information.

Axis 221 Specifications

General

Maximum resolution	640 x 480 pixels
Supported video modes	-
Video formats supported	MPEG4
Camera shutter speed	1/25000 - 2 s
Minimum illumination	0.08 lx
Sensor type	CCD
Progressive scan	Yes
Optical sensor size	1/3 \
Optical zoom	- x
Focus adjustment	1.0
Focal length range	3 - 8 mm
Built-in HDD	No
Flash memory	8 MB
Internal memory	32 MB
Type	IP security camera
Certification	EN 55022 B, EN 55024, EN 61000-3-2, EN 61000-3-3, \\r EN 61000-6-1, EN 61000-6-2, FCC 5 B B, \\r VCCI B, C-tick AS/NZS CISPR22, ICES-003 B, \\r EN 60950-1
Placement supported	Indoor
Connectivity technology	Wired
Form factor	Bullet
Product color	Gray
Housing material	Aluminum
Ethernet LAN (RJ-45) ports	1
Cabling technology	10/100Base-T(X)
Supported network protocols	IPv4/v6, HTTP, HTTPS, QoS Layer 3 DiffServ, FTP, SMTP, Bonjour, UPnP, SNMPv1/v2c/v3 (MIB-II), DNS, DynDNS, NTP, RTSP, RTP, TCP, UDP, IGMP, RTCP, ICMP, DHCP, ARP, SOCKS
AC input voltage	24 V
Power source type	PoE
Power consumption (typical)	7.5 W
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	20 - 80 %
Compliance industry standards	IEEE 802.3a

Weight and Dimensions

Weight	550 g
