AXIS 221 - Product Features
Network Connector - The camera connects to the network via a standard RJ-45 connector.
Supporting NWAY, the camera detects the speed of the local network segment
(10BaseT/100BaseTX Ethernet). This socket can also be used to power the AXIS 221 via
PoE (Power over Ethernet). The camera can also negotiate the correct power level when
using PoE.
RS-232 Connector- Single 9-pin D-SUB RS-232 connector, max 115 kbit/s, half-duplex.
Serial Number - This number is used during installation.
Reset Button - Press this button to install using the AXIS Internet Dynamic DNS Service or
to restore the factory default settings, as described in
Resetting to the Factory Default
Settings, on page 37.
LED Indicators
After completion of the startup and self test routines, the multi-colored Network, Status,
and Power LED indicators flash as follows:
Network Amber Steady for connection to 10 Mbit/s network. Flashes for network activity.
Green Steady for connection to 100 Mbit/s network. Flashes for network activity.
Red Flashes rapid red, together with the Status indicator, for hardware error.
Unlit No connection.
Status
Green Shows steady green for normal operation. Can be configured to flash green at intervals
whenever the camera is accessed. See the online help for more information.
Unlit When configured for “no flash” on camera access.
Amber Shows steady amber during reset to factory default or when restoring settings.
Red Slow flash for failed upgrade (see Emergency Recovery Procedure, on page 39).
Rapid flash, together with the Network indicator, for hardware error.
Power Green Normal operation.
Amber Flashes green/amber during firmware upgrade.
