AXISA1001NetworkDoorController
InstallationGuide-FullReference
ThisfullreferenceinstallationguideprovidesinstructionsforhowtoinstallAXISA1001Network
DoorControlleronyournetwork.
•Foraquickreferenceguide,seetheprintedAXISA1001InstallationGuide–Quick
Referencethatisincludedinthepackagecontents.Thequickreferenceguideisalso
availableonwww.axis.com
•Forotheraspectsofusingtheproduct,seetheAXISA1001UserManualavailable
onwww.axis.com
InstallationSteps
1.Makesurethepackagecontents,toolsandothermaterialsnecessaryfortheinstallation
areinorder.Seepage13.
2.Studythehardwareoverview.Seepage14.
3.Studythespecications.Seepage20.
4.Installthehardware.Seepage29.
5.Accesstheproduct.See.
Packagecontents
•AXISA1001NetworkDoorController
•Cabletie(4x)
•Coverscrew
•6-pinplugconnector(5x)(pluggedintoterminalconnectors)
-ReaderI/O(blue)
-ReaderI/O(red)
-Readerdata(white)
-Readerdata(yellow)
-Power&Relay(orange)
•4-pinplugconnector(5x)(pluggedintoterminalconnectors)
-Audio(white)
-Auxiliary(yellow)
-Doorin(blue)
-Doorin(red)
-Powerlock(orange)
•2-pinplugconnector(pluggedintoterminalconnector)
-Power(black)
13
EN

Axis A1001 Specifications

General

Interface	RS-485
Built-in UPS	-
Maximum number of doors	2 door(s)
DC voltage range	10 - 30 V
Power consumption (typical)	26 W

Weight and Dimensions

Depth	45.3 mm
Width	180 mm
Weight	500 g
