Axis A1001 Installation Guide

AXISA1001NetworkDoorController
Note
•WirelesslocksarenotsoldanddistributedbyAxisCommunications.Forsupportand
trainingrelatedtowirelesssystems,contactrelevantmanufacturers'partner.
•TheAxisproductisconsideredstandalone,anddoesnotrequireconstantconnectiontoa
computerforproperoperation.Theuseofaconnectedcomputerisforlocalprogramming,
downloading,andsupplementalmonitoringpurposesonly.
WallandCeilingMount
NO NO
NO
TICE TICE
TICE
Ifinstallingthedoorcontrolleronawall,makesurethecut-outforthecablesisfacing
downward.
1.Ifusingajunctionbox,installthejunctionboxbeforeinstallingthenetworkdoor
controller.ForULcompliance,thejunctionboxshallbeULListed.
2.Ifrequired,removethecoverscrew,insertaslottedscrewdriverintothecoverremoval
slotandremovethecover.SeeHardwareoverviewonpage14.
3.Makemarksforthescrewholesintheceiling/wall,usingthebaseasatemplate.
4.Ifrequired,drillholesforthescrews.
5.Mountthebaseonthewallorceiling.Makesurethatthescrewsandplugsare
appropriateforthematerial(e.g.wood,metal,sheetrock,stone).
30

Axis A1001 Specifications

General

Interface	RS-485
Built-in UPS	-
Maximum number of doors	2 door(s)
DC voltage range	10 - 30 V
Power consumption (typical)	26 W

Weight and Dimensions

Depth	45.3 mm
Width	180 mm
Weight	500 g
