Axis A1001 Installation Guide

AXISA1001NetworkDoorController
1
Base
2
Screwhole(4x)
3
DINrail
4
LowerDinclip
7.Securethebaseusingfourscrews.Makesurethatthescrewsandplugsareappropriate
forthematerial(e.g.wood,metal,sheetrock,stone).SeeWallandCeilingMounton
page30.
Note
Topreventbendingofthebase,becarefulnottotightenthescrewstootight.Leave
approximately2.5mm(0.1in).Ifthebaseisbent,thecoverwillnotclose.
8.Connectthecables.Seepage32.
ConnecttheCables
CAUTION
DisconnectpowerbeforeconnectinganywirestotheAxisproduct.Nevermakeconnections
whilepowerisappliedtotheproduct.
32

Axis A1001 Specifications

General

Interface	RS-485
Built-in UPS	-
Maximum number of doors	2 door(s)
DC voltage range	10 - 30 V
Power consumption (typical)	26 W

Weight and Dimensions

Depth	45.3 mm
Width	180 mm
Weight	500 g
