Axis A1001 Installation Guide

AXISA1001NetworkDoorController
NO NO
NO
TICE TICE
TICE
•Theproductshallbeconnectedusingashieldednetworkcable(STP).Allcablesconnecting
theproducttothenetworkshallbeintendedfortheirspecicuse.Makesurethatthe
networkdevicesareinstalledinaccordancewiththemanufacturer’sinstructions.For
informationaboutregulatoryrequirements,seeRegulatoryinformation4.
•IfusingPoweroverEthernet,waitwithconnectingthenetworkcabletothenetworkuntil
thealltheotherwireshavebeenconnected.
•Toallowforfuturemaintenance,toavoidexcessivestrainonwiresandconnectors,andto
avoiddamagetoconductorinsulation,leaveaserviceloopandmakesureallcablesand
wiresareproperlysupportedandsecured.Usethesuppliedcableties.
•Toprotectthecircuitsagainstelectrostaticdischarge(ESD),useESDprotectionwhen
connectingwirestotheproduct.
1.Loopthenetworkcablearoundthecableguideandconnectthenetworkcabletothe
networkconnector.
2.Securethenetworkcabletothecableguideusingoneofthesuppliedcableties.
1
Cabletie
2
Networkcable
33
EN

Axis A1001 Specifications

General

Interface	RS-485
Built-in UPS	-
Maximum number of doors	2 door(s)
DC voltage range	10 - 30 V
Power consumption (typical)	26 W

Weight and Dimensions

Depth	45.3 mm
Width	180 mm
Weight	500 g
