Axis A1001 Installation Guide

AXISA1001NetworkDoorController
iInput
ii
0VDC(-)
Installthehardware
CAUTION
NevermounttheAxisproductwhilepowerisappliedtotheproduct.Alwaysapplypower
attheendoftheinstallation.
NO NO
NO
TICE TICE
TICE
Toprotectthecircuitsagainstelectrostaticdischarge(ESD),useESDprotectionwhen
handlingtheproductwhilethecomponentsandcontactsareexposed.
Readalltheinstructionsbeforeinstallingtheproduct.
•Tocongurethehardware,seepage41.
•Toinstalltheproductonawall(preferred)orceiling,seepage30.
•ToinstalltheproductonaDINrail,seepage31.
•Toconnectthecables,seepage32.
SystemConsiderations
TheAxisproductshallbeinstalledwithinthesecuredarea.
TheAxisproduct,whetheritisinstalledasasingledoorcontrollerorinasystemofdoorcontrollers,
shallnotlimitorweakentheintendeduseofthedevicesconnectedtoit.
TheAxisproductshouldbeinstalledonawall(preferred)oraceiling,withorwithoutajunction
box.ItcanalsobeinstalledonaDINrail.
Systemsize
TheAxisproductcanbeconnectedtootherAxisNetworkDoorControllersinacontrollercluster
thatcanhandleupto66doorsorwirelessdevices(withinthecluster).EachAxisproductcan
connectuptotwowireddoorsoronewireddoortogetherwithonewirelessgateway.Theamount
ofwirelesslocksconguredtoeachgatewayisdependentonthemanufacturer.
29
EN

Axis A1001 Specifications

General

Interface	RS-485
Built-in UPS	-
Maximum number of doors	2 door(s)
DC voltage range	10 - 30 V
Power consumption (typical)	26 W

Weight and Dimensions

Depth	45.3 mm
Width	180 mm
Weight	500 g
