Axis A1001 Installation Guide

AXISA1001NetworkDoorController
1.InA1001,gotoSetup>HardwareCongurationandclickStartnewhardware
conguration.
2.EnteranamefortheAxisproduct.
3.SelectElevatorcontroltoincludeanAXISA9188NetworkI/ORelayModuleandclick
Next
4.Enteranamefortheconnectedreader.
5.SelectthetypesofreadersthatwillbeusedandclickFinish
6.ClickNetworkPeripheralstocompletethecongurationseeorclickthelinktogoto
thehardwarepinchart.
AddAssaAperio
TM
DoorsandDevices
BeforeaddingawirelessdoortothesystemitneedstobepairedwiththeconnectedAssaAperio
communicationhub,usingAperioPAP(Aperioprogrammingapplicationtool).
Toaddawirelessdoor:
1.GotoSetup>HardwareReconguration.
2.UnderWirelessDoorsandDevicesclickAdddoor.
3.IntheDoornameeld:Enteradescriptivename.
4.IntheIDeldunderLock:Enterthesix-character-longaddressofthedevicethatyou
wanttoadd.Thedeviceaddressisprintedontheproductlabel.
5.Optionally,underDoorpositionsensor:ChooseBuiltindoorpositionsensoror
Externaldoorpositionsensor.
Note
Ifusingaexternaldoorpositionswitch(DPS),makesurethattheAperiolockdevicehas
supportfordoorhandlestatedetectionbeforeconguringit.
6.Optionally,intheIDeldunderDoorpositionsensor:Enterthesix-character-long
addressofthedevicethatyouwanttoadd.Thedeviceaddressisprintedontheproduct
label.
7.ClickAdd.
PrerequisitesSmartIntego
ThefollowingprerequisitesneedstobemetbeforeproceedingwiththeSmartIntegoconguration:
•Acsv-leneedstobecreated.Thecsv-lecontainsinformationaboutwhat
GatewayNodeanddoorsthatareusedinyourSmartIntegosolution.Theleiscreatedin
astandalonesoftwareprovidedbyaSimonsVosspartner.
•TheHardwareCongurationofSmartIntegohasbeendone,seeHowtocreateanew
hardwarecongurationforwirelesslocksonpage42.
43
EN

Axis A1001 Specifications

General

Interface	RS-485
Built-in UPS	-
Maximum number of doors	2 door(s)
DC voltage range	10 - 30 V
Power consumption (typical)	26 W

Weight and Dimensions

Depth	45.3 mm
Width	180 mm
Weight	500 g
