AXIS P1347 Network Camera
Technical Specifications
Function/group
Item
Specifications
Audio streaming Two-way, full duplex
Audio
compression
AACLC8kHz32kbit/s,16kHz64kbit/s
G.711 PCM 8 kHz 64 kbit/s
G.726 ADPCM 8 kHz 32 kbit/s or 24 kbit/s
Configurable bit rate
Audio input
3.5 mm jack for mic/line in, max 80 mVpp for microphone/max 6.2 Vpp for line signal
Impedance: Min 1 kΩ, Mic-Power activated; Min 4 kΩ line
Tip: Signal/Bias
Ring: Bias
Sleeve: Ground
Power to external electret microphone: 1.3 V – 2.6 V (DC)
SNR: > 40dB
Audio output 3.5 mm jack for line out. max 2.8 Vpp
Impedance: max 100 Ω,normal<1Ω
SNR: > 40dB
Audio
Built-in
microphone
specification
Sensitivity: -36dB±2dB(0dB=1V/Pa,1kHz)
Max input (SPL): 100 dB
Security Password protection, IP address filtering, HTTPS encryption*, IEEE 802.1X network access
control*, digest authentication, user access log
*This product includes softw are developed by the Open SSL Project f or use in the Open
SSL Toolkit (www.openssl.org)
Network
Supported
protocols
IPv4/v6, HTTP, HTTPS*, SSL/TLS*, QoS Layer 3 DiffServ, FTP, SMTP, Bonjour, UPnP,
SNMPv1/v2c/v3(MIB-II), DNS, DynDNS, NTP, RTSP, RTP, TCP, UDP, IGMP, RTCP, ICMP,
DHCP, ARP, SOCKS
*This product includes softw are developed by the Open SSL Project f or use in the Open
SSL Toolkit (www.openssl.org)
Application
Programming
Interface
Open API for so ftware integration, including VAPIX® and AXIS Camera Application
Platform from Axis Communications; specifications available at www.axis.com
Includes the ONVIF specification available at www.onvif.org
Support for A XIS Video Hosting Syste m (AVHS ) with One-C lick Camera Connection
Intelligent video
Video motio n detection, active tampering alarm, audio detection, Support for AXIS
Camera Application Platform enabling installation of additional applications
Triggers
Intelligent video, day/night mode, digital I/O, manua l trigger, PTZ preset, PTZ moving,
network lost, stor age status, system initializing
Actions File upload via FTP, HTTP and
email
Notification via email, HTTP and TCP
Video and audio recording to edge storage
Pre- and post-alar
m vide o buffering
External output activatio n
PTZ preset
Guard tour
Play audio clip
Status LED
Day/ni
ght vision mode
Video access from
web b rowser
Camera live view
Video recording to file (ASF)
Customizable HTML pages
Windows 7, Windows V ista, Windows XP, Wind ows Server 2008, Windows Server 2003
DirectX 9c or higher
For other operating systems and browsers, see www.axis.com/techsup
System
Integration
